74 ProSYS Installation and Programming Manual
Zones: Loop Response
Quick Keys Parameter
Notes:
1. Loop response times 0.5 hour to 4 hours can be assigned only to zones 1 to 8
on the Main Panel or to zones located on the fast zone expander
RP128EZ8F00A
2. The programming option of loop response 0.5 hour to 4 hours will be between
4-11 for zones located on the main menu while on the fast zone expander
RP128EZ8F00A the programming location is between 5-12
22
77
Zones: Cross Zones
Default: No cross zoning
The Cross Zone menu is used for additional protection from false alarms and contains
parameters that enable you to link together two related zones. Both must be violated within a
designated time period (between 1 and 9 minutes) before an alarm occurs.
This type of linking is used with motion detectors in hostile or false-alarm prone
environments.
NOTE:
The ProSYS allows 10 unique sets of zone links (pairs of zones), which can be manually specified, as
required.
 To access the Cross Zone menu:
1 Access the Zones menu, as described on page 62.
2 From the Zones menu, press [7] to access the Cross Zone menu options. The first
zone link appears:
3 Press
/ to modify the first set (01) of zone links.
4 Select the zone pairs manually, as required, by making changes to the number of the
first zone in the set, followed by the number of the second zone. If necessary, use the
/ or / keys to position the cursor.
NOTES:
Zones crossed with themselves are valid pairs. They need to register a violation twice to trigger the
alarm. This process is known as Double Knock.
You may want to establish a number of zone links, but leave them deactivated at this time (see below).
5 Press / to determine how the ProSYS will process violations of the
paired zones.
6 Access and configure the paired parameters in the Cross Zone menu, as follows:
Zones: Cross Zone
Quick Keys Parameter Default
To Next Page
