ProSYS Installation and Programming Manual 129
Dialer: Report Split
Quick Keys Parameter Default
[10] Phone Trouble
Restore
N
[11] GSM Low
Battery Restore
N
[12] GSM Trouble N (Restore of all GSM module faults)
[13] Siren Low
Battery Restore
N
2. After you have defined all the required phone events, press
/
.
55
77
55
E-mail
To enable event reporting using the ACM, the following parameters should
be defined:
[1] Mail IP Address: The IP address of the ACM mail server.
[2] Mail SMTP PRT: The port address of the ACM SMTP mail server port,
used to send messages.
[3] Mail POP3 PRT: The port address of the ACM POP3 mail server port,
used to retrieve e-mails.
[4] E-mail Prefix: The ACM email address prefix; 16 characters are used to
define the ACM email prefix (for example in the ACM@riscogroup.com e-
mail address, the prefix name is “ACM”).
[5] E-mail Domain: The ACM email address domain name, which identifies
the web server of the ACM. For example, in the email address
ACM@riscogroup.com, the domain name is riscogroup.com. (Do not enter
the @ sign.)
[6] SMTP User Name: A parameter that defines the user name that the
SMTP server requires for authentication when defined as such by the IT
department. Up to 21 characters can be used.
[7] SMTP Password: A parameter that defines the password that the SMTP
server requires for authentication when defined as such by the IT
department. Up to 21 characters can be used.
55
77
66
Event Log
The ACM will enable storing of unlimited amount of events over Ethernet
resources, which can be used for backup and analysis.
[1] Enable
[2] E-Log IP Address
[3] E-log Port
To Next Page
