Risco ProSYS series User Manual

200 ProSYS Installation and Programming Manual
Appendix A : Technical Data
Main Panel
Input Power
16.5 Volts AC @ 40 Volt-Amps (VA) (via integral transformer)
Current Consumption
60 mA, typical / 70 mA, maximum
Rechargeable Standby
Battery
12 Volts up to 17 Amp-Hours (AH), typical
Power Outputs:
O Auxiliary Power
12 Volts DC @ 600 mA, maximum (from all AUX terminals)
O Bell/LS (External)
Sounder Output
12 Volts DC @ 900 mA, maximum
Programmable Voltage
(Utility) Output
UO1: Relay (programmable output) (3 Amps)
UO2: 500 mA transistor
UO3-UO6: Open Collector Active Pull-Down, 70 mA, max.
Cabinet Dimensions
37.5 cm x 33 cm x 9.8 cm
Main Board Dimensions
20 cm x 11.5 cm x 6.5 cm
Fuses F3
Responsible for:
Battery Power
3.0 A
AUX
Automatic fuse
BELL
Automatic fuse
Keypads (8 LED/16 LED/KCL/KCLP)
Current Consumption
8 LED 75 mA maximum
16 LED 75 mA maximum
KCL 100 mA maximum
Proximity KCL 160 mA maximum
Main Panel Connection
4-wire BUS, up to 300 m from Main Panel
Dimensions
16.2 cm x 12.2 cm x 3 cm
Touchscreen Keypads
Current Consumption
ProSYS KP 30 mA typical / 180 mA maximum
ProSYS KPP (with
proximity)
30 mA typical / 210 mA maximum
Main Panel Connection
4-wire BUS, up to 300 m from Main Panel
Dimensions
21 cm x 15.2 cm x 2 cm
Zone Expansion Module: 8-Zone
Current Consumption
25 mA, typical / 45 mA, maximum
Main Panel Connection
4-wire BUS, up to 300 m from Main Panel
Dimensions
10.5 cm x 6.6 cm x 1.8 cm

Risco ProSYS series Specifications

General

Communication	IP, GSM, PSTN
Wireless Protocol	Two-way wireless
Battery Backup	Yes
Remote Control	Yes, via app
Integration	RISCO Cloud
