ProSYS Installation and Programming Manual 65
6 Use the
/ or / keys to select the group and use the /
key to toggle between
[Y] YES and [N] NO.
NOTE:
Each partition has 4 groups. The zone group definition is common to each of the partitions assigned to
the zone.
22
33
Zones: Zone Type
The Zone Type menu contains parameters that enable you to program the zone type for any
zone. Setting the zone type is partly determined by the arming levels. Three arming levels
exist, as follows:
Disarm: The system reacts only to those zones defined as 24 HR, Fire, Panic, and Trouble.
Arm: The system reacts to all zones.
Stay: The system does not react to zones defined as internal (home). This setting allows
freedom of movement in those zones.
There are 23 zone types in the system, as described in the following procedure.
 To access the Zone Type menu:
1 Access the Zones menu, as described on page 62.
2 From the Zones menu, press [3] to access the Zone Type menu options. The following
display appears:
3 Specify a two-digit zone number and press
/
.
4 Access and configure the parameters in the Zone Type menu, as follows:
Zones: Zone Type
Quick Keys Parameter Default Arming Level/Range
22
33
ZZZZ
+
/
0000
Not Used
NONE
Disables a zone. All unused zones should be given this designation.
22
33
ZZZZ
+
/
0101
Exit/Entry 1
Arm/Stay
Used for Exit/Entry doors.
Zones in the Exit/Entry path, that when violated do not cause an intrusion
alarm during the Exit/Entry Delay periods (refer to Exit/Entry Delay 1 and
Exit/Entry Delay 2, page 47).
A zone must be secured during arming and when the delay expires. Use this
zone to trigger the entry delay.
22
33
ZZZZ
+
/
0202
Exit/Entry 2
ARM/STAY
Same as above, except that the Exit/Entry 2 time period applies.
To Next Page
