ProSYS Installation and Programming Manual 33
O Connect one (or more) normally open (NO) momentary-action pushbutton switches
in a series between the TAMP and COM terminals in order to short-circuit these
terminals while the cabinet door is closed.
NOTES:
It is not necessary to use a tamper switch if another module sharing the same cabinet is
equipped with one.
Do NOT use an End-of-Line Resistor in the tamper switch circuit.
O If a tamper switch is not used, connect a wire jumper between the two terminals.
4 Mount the Utility Output Expansion Modules: Mount one or more Utility Output
expansion modules in the Main Panel cabinet, depending on space availability.
Alternatively, mount them in a separate cabinet.
5 Connect the Triggerable Device to the Utility Output:
O Connect one wire to the COM terminal of the UO device to be operated and connect the
other wire to the GND.
O Connect the NO or NC switch to the AUX terminal.
6 Wire the Relay Connections: The Relay module has 4 relays (UO1, UO2, UO3, and
UO4), which can be connected as follows:
O Connect one wire of the device to be operated to the UO terminal.
O Connect the other wire of the device to be operated to the AUX terminal.
For instructions about programming the relay operation, refer to the Utility
Output section in Chapter 5, Using the Installer Programming Menus.
7 Wire the Triggers: The Open Collector modules have 8 outputs (UO1 through UO8).
For instructions about programming their operation, refer to the Utility Output section in
Chapter 5, Using the Installer Programming Menus.
8 Wire the X-10:
O Connect the 4-wire BUS between the Main Panel and the X-10 module.
O Connect an RJ25 cable (4-wire telephone cable) between the RJ11 connector on the
X-10 module and the X-10 transmitter.
O Plug the X-10 transmitter into the AC power.
O Plug the X-10 receiver into the AC power close to the device that will be operated.
O Connect the X-10 receiver to the device.
For more information about programming and setting the ID of the X-10
module, refer to the instructions supplied with the module
