Mixed signal option (MSO, R&S RTP-B1)
R&S
®
RTP
939User Manual 1337.9952.02 ─ 12
Source
If the Mixed Signal Option is installed, the variety of trigger sources is enhanced with
specific digital trigger sources. As a trigger source you can select:
●
One of the digital channels "D0" ... "D15"
D2D0 D1
●
A logic combination of digital channels: "Logic"
●
One of the parallel buses "Par. bus1" ... "Par. bus4"
PB
3
PB
2
PB
1
Remote command:
TRIGger<m>:SOURce[:SELect] on page 1253
Type
Depending on the selected source, the instrument provides the appropriate trigger
types and the corresponding trigger settings. For mixed signal analysis, the following
trigger types are available:
●
Edge, see page 939
●
Width, see page 940
●
Timeout, see page 942
●
Setup & Hold, see page 943
●
State, see page 945
●
Pattern, see page 946
●
Serial pattern, see page 948
Remote command:
TRIGger<m>:PARallel:TYPE on page 2209
14.3.1.2 Edge
Using the edge trigger, you can also trigger on a single digital channel (a logic bit), and
a logical combination of digital channels.
Depending on the selected trigger source, different trigger settings are available. The
trigger level is already set - in MSO the logical threshold is used as trigger level.
