Specifically the batch objects are:
● Batch types:
– Data types
– Units of measure
– Operation types, phase types, and process tag types > process tag type > process tag
type parameters → currently selected element
By selecting the appropriate folder, you can create new operation types, phase types,
and process tag types; by selecting a created object, you can edit its process tag type
parameters.
– Equipment properties
● Batch instances:
– Process cell (folder)
– Units (folder)
– Equipment properties
– Equipment modules (EMOD) (folder)
– Neutral folder
– Equipment phases (EPH)
– Parameters of equipment phases
– Equipment operations (EOP)
– Parameters of equipment operations
– Process tags
– Process tag parameters
Runtime name in the dialog header
Display of the runtime name.
Process cell data
For navigation in the process cell data.
Parameters
Name of the object selected in the navigation tree.
Description Any object description by the user.
Data type Assign the desired data type to the process tag type parameter from the
drop-down list. All standard data types and user data types are available
for selection. You must specify desired user data types beforehand under
"Data types".
Button: Data type Activating this button takes you to the appropriate batch data type. Use the
Back button on the batch data type to return to this point.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 1001
