External process cell
Button
Check validity This checks whether all locations you have configured in the source project
are plausible for SIMATIC BATCH and can be used.
Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging function is activated with the "Display" button. The selec‐
ted log is generated as an XML file in the specified layout and shown
in Internet Explorer.
Select "Process cell" and click on the "Display" button to show all proc‐
ess cell errors or warnings. You can also right-click on a selected object
and select the "Display Log" function to display object-specific errors
or warnings.
OK button
Saves your settings and closes the dialog.
Apply button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
14.1.12.66 Control strategies of...
In this dialog box, you assign the parameters to a control strategy. Later in batch control, only
the parameters selected here are taken into account for this control strategy. If the control
strategies are restricted for the instance (EPH or EOP) assigned to the phase type or operation
type, only the control strategies enabled here can be used later in the recipe.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 955
