Procedure
1. Create a new library operation / library substructure in the Batch Control Center.
2. Open the "Properties" dialog of the library operation or library substructure and open the
"Allocations" tab.
3. Click on the "Edit" button and open the "Candidates" tab.
4. Activate only the desired unit class and close all dialogs.
Result
The selection for library references in a recipe is limited to the unit class by the filter criterion.
10.4.6 Setting recipe properties
10.4.6.1 Passing formula parameters in the recipe
Forwarding the formula parameters in the recipe
The same formula parameter can be used more than once in different recipe steps of various
types. A formula parameter can also be used at the same time in transition conditions.
The schematic below shows the possible use of a formula parameter.
)RUPXOD5HFLSHSURFHGXUH
1DPH
9DOXH
1DPH
9DOXH
5HFLSHXQLWSURF
5HFLSHRSHUDWLRQ
5HFLSHSKDVH
(TXLSSKDVH
1DPH
7DUJHW
9DOXH
1DPH
1DPH
9DOXH
1DPH
7DUJHW
1DPH
9DOXH
1DPH
7DUJHW
1DPH
9DOXH
BATCH Recipe Editor
10.4 Creating recipes
SIMATIC BATCH V8.2
560 Operating Manual, 02/2016, A5E35958174-AA
