Specifies whether or not a filter will be displayed for each table column. If yes is set, a filter
row is inserted in the control; if no is set, no filter row is inserted.
The attribute can be dynamized with the ProjectListColumnFilterVisible name.
11.5.1.9 ToolbarOrderAndVisibility
String.
Specifies the sequence of the elements in the toolbar. If individual values are not specified,
the corresponding toolbar symbols are not displayed. The value 0 is used as a separator
(grouping of symbols). The table below lists the elements and their values:
Toolbar elements Symbol Symbol menu Value
Dock/undock 1
Undock automatically 6 / -6
Change 7
8
9
10
Activate project 2
Deactivate project 3
Update loaded project 4
Update project list 5
Important system messages 11 / -11
The settings made here also influence the shortcut menu.
The values are separated by a semicolon and entered in the following syntax, for example:
1;2;3;4;5. Putting the toolbar elements in a different sequence would, for example, produce
the following values: 2;;1;3;;4;5. Putting two semicolons between single digits is the same as
a vertical line between the toolbar elements. The example results in the following toolbar:
Use a negative or a positive value to specify whether or not the function "Undock automatically"
should be used by default. Example: If you enter the value -6 instead of the specified value 6
for the attribute for the "Undock automatically" function, the button is displayed in the OS control
as pressed, that is, the OS Control is automatically shown as undocked.
The attribute can be dynamized with the ToolbarOrderAndVisibility name.
11.5.1.10 ToolbarVisible
Boolean variable.
BATCH OS controls
11.5 Control properties references
SIMATIC BATCH V8.2
644 Operating Manual, 02/2016, A5E35958174-AA
