Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
14.1.12.50 "AF" selection
Equipment procedural element selection
In the list "Process data" you have selected the object "Equipment procedural elements".
Runtime name in the dialog header
Display of the runtime name.
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the process cell tree.
Description The description of the interface block is displayed in this text box. You enter
description texts in the object properties in SIMATIC Manager.
Runtime name Corresponds to the WinCC variable name plus the OS name as prefix.
CFC chart CFC chart name in which the block is placed.
"Open" button
Not possible in the multi‐
project.
Click on the "Open" button to open the appropriate CFC chart and select
the block.
Assigned phase type: Type definition for process cell-neutral recipe creation.
"Type" button Activating this button takes you to the corresponding block type. With the
Back button of the block type, you return to this location.
Block
Button
Compile
This button only exists for
a project and not for a
multiproject.
All batch instance blocks of the CFC chart of the selected object are read
in. This also implicitly involves a check for consistency with the batch types
and conformity to ISA-88.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 935
