Display of the allocation status – flat recipe
Display Name Meaning
53+
Waiting for unit The control wants to allocate the unit required
by the RPH
Either allocated by another RPH, or there are
not enough memory blocks.
53+
Unit allocated The control has allocated the unit required by
the RPH
53+
Unit allocated and waiting
of equipment phase
The control wants to allocate the equipment
phase required by the RPH
53+
Unit and equipment phase
allocated
The control has allocated the RPH
53+
Allocation error Allocation error or connection failure
Missing AS-OS connec‐
tion
OS has no connection to the AS
Additional information
BATCH configuration dialog > "Chart folder" tab (Page 949)
9.8.5.14 Additional status identifier
Additional status IDs - breakpoint and command
The breakpoint is indicated by a red circle. The circle is replaced by the breakpoint operator
button when the step is activated. The symbol for the breakpoint operator button corresponds
to the start icon on the toolbar.
The pending command is indicated by a symbol corresponding to the operator button.
BATCH Control Center
9.8 Batch control
SIMATIC BATCH V8.2
434 Operating Manual, 02/2016, A5E35958174-AA
