53+53+
53+RFFXSLHG81,753+RFFXSLHG(3+
53+53+
DQG
Display of the allocation status – hierarchical recipe
Display Name Meaning
Waiting for unit The control wants to allocate the unit required
by the RUP
Either allocated by another RUP, or there are
not enough memory blocks.
The unit can only be allocated when the
PCS 7 OS server is completely in process
mode.
Unit allocated The control has allocated the unit to the RUP
ROP running The control has allocated the ROP
Waiting for equipment
phase
The control wants to allocate the equipment
phase required by the RPH
Equipment phase alloca‐
ted
The control has allocated the RPH
Allocation error Allocation error or connection failure
Missing AS-OS connec‐
tion
OS has no connection to the AS
BATCH Control Center
9.8 Batch control
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 433
