Apply button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
14.1.12.46 Translate "Batch instances" selection
Batch instances selection
You have selected the "Batch instances" object in the "Process cell data" list.
Display field under dialog title
Logical path display
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the process cell tree.
Description Enter a description for the batch instances in this text box.
Last compiled on Local time stamp of the last compilation.
Batch instances
Button
Compile If a process cell, standardized according to ISA-88, are located in your PCS 7 project,
the button is then activated or useable.
All batch instance blocks of all CFC charts in the project (UNIT/EPH/EOP, EPAR*,
IUNIT/IEPH/IEOP, IEPAR, TAGCOLL and SFC type blocks) are read in. This also im‐
plicitly involves a check for consistency with the batch types and conformity to ISA-88.
The validity errors and validity warnings are displayed in the log field and can be vi‐
sualized using the "Display" button.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 929
