Siemens SIMATIC BATCH User Manual

7.3.18 Specifying the type description of the process cell
7.3.18.1 Type description of the process cell
Introduction
As the basis for creating recipes in SIMATIC BATCH, the type description of the process cell
must be generated or edited and, where necessary, synchronized with the block instances of
the CFC charts. The following types can be defined for creating recipes.
Batch types (type description of a process cell)
Type Editing options and results
Data types The system specifies the standard data types floating point number, integer,
string, input material, output material, material (V4), and Boolean.
You can also create custom data types and edit their properties.
Units of measure You can create new units of measure and edit their properties.
Engineering
7.3 BATCH engineering
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 211

Siemens SIMATIC BATCH Specifications

General

Brand	Siemens
Model	SIMATIC BATCH
Category	Control Systems
Language	English
