If errors occur in the validation, the problems are displayed and the recipe status remains "In
Progress...". Release is also possible in the BATCH Recipe Editor.
Note
If the recipe is open in the BATCH Recipe Editor, you can also jump to the part of the recipe
that caused the problem by double-clicking the entry in the error list.
9.5.6.4 Releasing recipes for production
Requirement:
The prerequisite in this regard is the validity of the recipe. The validity is first checked
automatically with this command.
Proceed as follows in the BatchCC
1. Select the recipe (master recipe or library operation) in the tree structure.
2. Select the menu command Edit > Release for production.
Result: After it has been released, the recipe has the "released for production" status. If
errors occur in the validation then these deficiencies are displayed and the recipe status
remains in "in progress". The release can also be executed in the BATCH Recipe Editor.
Note
If the recipe is open in the BATCH Recipe Editor you can go from the error list to the part of
the recipe causing the error by double clicking on the list entry.
9.5.6.5 Validating formulas
Definition
During validation, the formula is checked to make sure that a released master recipe is
assigned. The consistency of the formula parameters and their interconnections with the
parameters of the master recipe are also checked.
Requirements:
● A master recipe released for testing or production is assigned.
● The formula parameters were interconnected successfully
● The formula parameters are within the upper and lower limit values
BATCH Control Center
9.5 Recipes
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 317
