Properties
Name of the object selected in the process cell tree.
Description A comment is displayed that you have entered in the SIMATIC Manager in
the "Object properties" for the multiproject or project.
Multiproject/Project
Button
Settings The button is only displayed for a single project and multiproject.
If you click this button, another dialog opens with the following four tabs:
● Distribution
● OS objects
● Process cells. Only on the multiproject
● System characteristics
"OK" button
Saves your settings and ends the dialog.
Accept button
Your settings will be saved without closing the dialog. The button is only available if you have
made changes in the dialog.
"Cancel" button
Closes the dialog without saving changes.
"Help" button
Opens the SIMATIC BATCH help for this context.
14.1.12.8 "Batch process cell" selection
You have selected the "Batch process cell" object in the "Process cell data" list.
Path in the topmost display field
Logical path within the navigation tree.
Process cell data
For navigation in the process cell data.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 867
