Additional functions
Display of possible additional functions.
OK button
Saves your settings and closes the dialog.
Apply button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
14.1.12.30 "Process cell" selection (V4.02)
Process tag selection
In the "Process cell data" list you have selected the "process tag" object.
Run time name in the dialog header
Display of the run time name.
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the process cell tree.
Description Description: You can display or enter the description of the interface block
in this text box. You can enter a descriptive text in the object properties in
the SIMATIC Manager.
Runtime name Corresponds to the WinCC variable name plus the OS name as prefix.
CFC chart CFC chart name in which the block is located.
"Open" button
Not possible in the multi‐
project.
Click on the "Open" button to open the appropriate CFC chart and select
the block.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
904 Operating Manual, 02/2016, A5E35958174-AA
