12.4 What effects do changes to SFC types have on SIMATIC BATCH?
Changes to the configuration with and without changing the interface
Changes to SFC types in the PCS 7 basic engineering may or may not lead to interface
changes. Depending on this, the configuration procedures to update your batch process cell
will differ. Updating the batch process cell also has effects on the behavior of batches in process
mode and also on objects you have created in the BatchCC.
Changes to the SFC type Interface change?
Adding parameters
Yes
Deleting parameters
Changing the type of the parameter (for example Bool to Real)
Renaming parameters
No
Changing setpoint limits
Changing the unit of a parameter
Changes to the step and transition configuration
The term "Parameter" used in the table means only BATCH-relevant parameters such as
control strategies and setpoints.
Flowchart for configuration steps
The following flowchart illustrates the steps in configuration for changes in the PCS 7 basic
engineering and in the SIMATIC BATCH engineering.
Note
Any changes to the project must always be clarified with all the configuration engineers
involved in the project.
Recommended procedure
12.4 What effects do changes to SFC types have on SIMATIC BATCH?
SIMATIC BATCH V8.2
676 Operating Manual, 02/2016, A5E35958174-AA
