Available phases:
● For unit selection without conditions:
For recipes, the equipment phases still available after taking into account the restrictions
are displayed (intersection).
For library operations, if several unit classes are selected, the union set of equipment
phases is displayed.
● For unit selection with conditions:
The union set of all selected units is displayed under "Available phases".
Note
The selection of "Strategy" or "Preferred unit" has no effect on the display of the available
phases. The phases corresponding to the selected units under "Equipment selection" are
displayed here. All possible phases are shown at first (union set). Once phases are selected
in the recipe (phases used), the available units and therefore the phases displayed here
are filtered.
14.1.3.2 "Input material" tab (Procedure/Step/Formula/Batch properties)
The input materials are listed in the properties of the header (recipe procedure), the unit
recipes, the steps, the formula category, formula and batch.
For steps with a link to EOP, EPH or for operator dialogs, the entries are taken from the basic
engineering and for library sequences from the library object. Parameters can be created and
deleted in the other objects.
In the formula category, you can specify the parameters that are not specific to the procedure
as data structures. In the formula, you enter the "genuine" recipe values for the data structure.
Button for showing and hiding table columns
After the "Unit of measure" column listed below, there is an empty column with a button for
hiding or showing the following columns. This allows you to make the Parameters tab clearer
and simpler.
Button for printing parameters
Using a button in the table view, you can open a shortcut menu for printing the displayed
parameters. If you click the Print button in the shortcut menu, the table view along with the
parameters is output immediately to the default printer set in Windows.
If you click Print..., a Windows dialog opens in which you can select another printer set up in
Windows. If you click "OK" after making the selection, the parameters are printed.
List:
● Name: For steps that are linked to an EOP, EPH or library sequence, the name is adopted
from the ES or from the library object. You can specify a name for the other steps.
● Material (set): You can select from the input materials created in BatchCC. Click the button
to the right of the text box to open a dialog in which you can select the materials.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
758 Operating Manual, 02/2016, A5E35958174-AA
