"Cancel" button
Exits the dialog without saving your settings.
"Help" button
Opens the online help for this dialog.
14.1.2.7 Installed plug-in modules dialog box
From the installed modules shown in this dialog, you select the modules that will later be used
by SIMATIC BATCH. Select a row and then click "OK".
The dialog lists all installed modules that are not yet being used by SIMATIC BATCH. The
modules are installed on the computer. The icon indicates the status of the module.
This dialog also allows you to add plug-in modules whose files are on the computer but that
are not yet known to SIMATIC BATCH. This is useful when the module could not be registered
automatically as a SIMATIC BATCH Plug-in (for example if the module was installed before
SIMATIC BATCH).
Note
The PlugIn DLL to be used should be stored on the local PC, ideally in the BATCH installation
folder. If the DLL file is addressed in another directory, on a network drive or via a network
path, this can lead to malfunctions and error messages due to missing windows user
permissions.
Status display for the modules
Icon Description
Module cannot be used, however module is registered for the current project:
This means that SIMATIC BATCH cannot execute all functionalities. This status is obtained if, for ex‐
ample, a module is registered but in the meantime it has been deleted or renamed.
Module usable.
This does not mean that the module will actually be used. To find this out, the dialog has to be opened
with the "More" button.
Module exists but the internal logic of the module is signaling a problem.
Add
Adds installed modules that are not yet known to SIMATIC BATCH.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
738 Operating Manual, 02/2016, A5E35958174-AA
