Duration of the RPH 10 min
Duration of the transition 10 s
Acquisition cycle of the archive tags 10 s
Execution of step change simultaneous
3.6.4 Measured results for calculating the performance of both operating modes
The measured values depend on the project, the equipment and load of the PC being used
and can differ from the times shown here. The times were calculated with the hardware
recommended by SIMATIC PCS 7.
Result, measured value (offline)
For the measured times, it is assumed that the step changes execute simultaneously and are
not processed with a time offset. Simultaneous step changes mean maximum load.
Acquired data:
Action Runtime
Creating a recipe / library < 2 s
Deleting a recipe / library < 4 s
Creating a formula < 2 s
Deleting a formula < 2 s
Creating a material < 2 s
Deleting a material < 2 s
Releasing for testing / production < 90 s
Opening a recipe / library < 4 s
Checking a recipe for validity / releasing < 75 s
Creating an order < 2 s
Creating a batch < 20 s
Release batch < 75 s
Result, measured value (online)
When processing the basic recipe described, a PC equipped with a size of the SIMATIC
BATCH online database has a 30% processor load.
Definition of step change: A step change means that a recipe phase was completed, a transition
run through and the following recipe phase was started. This means that at least 3 recipe
objects are involved in a step change. In practice, however, there are often more than 3 recipe
objects involved, for example in simultaneous branches, alternative branches or when there
is synchronization. As an average value, approximately 5-7 recipe objects are assumed per
step change.
Action Runtime
Start batch < 3 s
HOLD command < 2 s!
Product introduction and installation
3.6 Configuration limits
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 71
