11.5.2 SIMATIC BATCH OS Allocation
11.5.2.1 CommunicationChannel
String.
Defines the communication channel for the selected BATCH project. Select the same
communication channel that you use in the "SIMATIC BATCH OS Master" control. This
ensures that you obtain the data for the unit allocation from the relevant BATCH project.
Default value = 1.
The attribute can be dynamized with the CommunicationChannel name.
11.5.2.2 FilterUnitName
Boolean variable.
With this attribute, you set a filter criterion for the "Unit" table column. Only the units with the
specified name pattern are listed. You can include wildcards in the name pattern. The following
wildcards are possible:
● ?: Wildcard for exactly one character.
● *: Wildcard for any number of characters.
Example: Entering the criterion "M*vessel". Returns all units with the initial letter "M" followed
by any number of characters and the postfix "vessel".
If there is only one unit displayed, a batch running on this unit will be displayed automatically
in the SIMATIC BATCH OS Properties control.
Default: Yes
The attribute can be dynamized with the FilterUnitName name.
11.5.2.3 ColumnWidth
String.
Specifies the width of the table columns in the control. The specified column width does not
depend on the column arrangement. The default values for column width are as follows:
Table column Column width in pixels
Unit 140
Batch 120
Batch runtime 50
Order category 75
Order 75
Master recipe 100
RUP (recipe unit procedure) 100
RUP runtime 50
ROP (recipe operation) 100
BATCH OS controls
11.5 Control properties references
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 647
