Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging is activated with the "Display" button. The selected log is
generated as an XML file in the specified layout and displayed in In‐
ternet Explorer.
Select "Process cell" and click the "Display" button to show all process
cell errors or warnings. You can also right-click a selected object and
select the "Display log" function to display object-specific errors or
warnings.
Additional functions
Instances
"Display" button All instance parameters that refer to this unit of
measure are listed in a dialog box. Certain attrib‐
utes can be selected by means of a special filter.
Or no instance exists.
OK button
Saves your settings and closes the dialog.
Apply button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
14.1.12.19 "Phase types" selection
Phase types selection
In the "Process cell data" list you have selected the "phase types" object.
Run time name in the dialog header
Display of the run time name.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
884 Operating Manual, 02/2016, A5E35958174-AA
