Siemens SIMATIC BATCH User Manual

Properties
Name of the object selected in the process cell tree.
Description You can display or enter the description of the operation type parameter in
this text box.
Assigned data type Assign the required data type to the type parameter. All standard data types
and user data types are available for selection. You must declare required
user data types under the shared declarations and make them available by
using the "Generate" function in SIMATIC BATCH.
"Data type" button Activating this button takes you to the corresponding data type. With the
"Back" button of the data type, you return to beginning selection.
Assigned unit of measure Assign the unit of measure to the type parameter. You must declare re‐
quired units of measure under "Units of measure" in the shared declarations
and make them available by using the "Generate" function in SIMATIC
BATCH.
"Unit of measure" button Activating this button takes you to the appropriate unit. With the "Back"
button of the unit of measure, you return to this location.
"Archive measured val‐
ue" check box
Select this check box if you wish to establish a connection to a WinCC
archive tag for the instance parameters. This selection is required for as‐
signing instance parameters to WinCC archive tags. You then make this
assignment on the instance parameters of the corresponding operation
type.
"Test manufacturing in‐
struction" check box
A type parameter is selected here if it is to be provided in the batch log for
the manual check (manufacturing instruction).
"Control strategy parame‐
ter" check box
If this check box is selected, you can make the control strategy settings for
this type at the type parameter.
This option is only available after at least one control strategy type has been
configured under data types.
Events log ID: Here, you can specify a value from 0 to 65535 that can be evaluated later
in a user batch report to allow filtering. Different values are permitted for
setpoint and process value. This means, for example, that you could filter
according to setpoints with setpoint ID < 1000 AND setpoint ID ≥ 500 and
according to process values with process value ID ≤ 2000. The user can
specify how convenient such a query is in his log software.
Parameters
Button
Delete Click "Delete" to delete the selected operation type parameter.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 883
