Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The "Display" button activates the logging. The selected log is gener‐
ated as an XML file with the specified layout and displayed in Internet
Explorer.
With the "S7 program" selection, all errors or warnings related to the
S7 program are displayed. When you select an object, you can also
right-click and select the "Display log" function to show errors or warn‐
ings for an individual object.
"OK" button
Saves your settings and ends the dialog.
"Apply" button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
"Cancel" button
Closes the dialog without saving changes.
"Help" button
Opens the SIMATIC BATCH online help for this context.
14.1.12.2 "CPU" selection
In the "Process cell data" list you have selected the "CPU" object.
Runtime name in the dialog header
Logical path within the navigation tree
Process cell data
For navigation in the process cell data
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
858 Operating Manual, 02/2016, A5E35958174-AA
