14.1.12.45 Convergence of "Batch instances" selection
Batch instances selection
You have selected the "Batch instances" object in the "Process cell data" list.
Display field under dialog title
Logical path display
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the process cell tree.
Description Enter a description for the batch instances in this text box.
Last changed on This displays the local time stamp of the last change for the batch instances.
Batch instances
Button
Merge If projects with process cells, standardized according to ISA-88, are located
in your PCS 7 multiproject, the button is then activated or useable.
Pressing this button opens the "Merge/compile" dialog for all the projects
available in the multiproject. This action also effectively results in the prop‐
agation of all selected projects.
Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging function is activated with the "Display" button. The selec‐
ted log is generated as an XML file in the specified layout and displayed
in Internet Explorer.
Select "Process cell" and click "Display" to show all process cell errors
or warnings. You can also right-click on a selected object and select
the "Display Log" function to display object-specific errors or warnings.
OK button
Saves your settings and closes the dialog.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
928 Operating Manual, 02/2016, A5E35958174-AA
