Batch process cell
Button
Generate Use this button to start the dialog "Generate types - entire process cell" to
generate or import the batch types. All SFC types (EPH, EOP), all BATCH
interface blocks in the CFC charts from which the types are generated, and
the shared declarations (enumerations, units, and equipment properties)
are read in from the projects you have selected.
Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging is activated with the "Display" button. The selected log is
generated as an XML file in the specified layout and displayed in In‐
ternet Explorer.
Select "Process cell" and click the "Display" button to show all process
cell errors or warnings. You can also right-click a selected object and
select the "Display log" function to display object-specific errors or
warnings.
Additional functions
Button
Print Prints all batch types of the process cell in tabular form.
OK button
Saves your settings and closes the dialog.
Apply button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 927
