"Help" button
Opens the SIMATIC BATCH help for this context.
14.1.12.12 "Data type" selection
Selection data type
In the "Process cell data" list you have selected the "Data type" object.
Path in the topmost display field
Logical path within the navigation tree.
Process cell data
For navigation in the process cell data
Properties
Name of the object selected in the process cell tree.
Description You can display or enter the description of the data type in this text box.
For standard data types a description text is specified and you cannot change it.
For user data types enter the description texts within the global declarations under
enumeration when selecting an object in the object properties in the SIMATIC Man‐
ager.
Control strategy The check box is only displayed for user data types.
The mode of operation can be activated or deactivated in the SIMATIC Manager
within the global declarations under enumerations, when selecting an object, in the
object properties.
Data type
No functions available.
Log
"Errors" display field The number of errors for the selected log are displayed.
"Warnings" display field The number of warnings for the selected log are displayed.
"Display" button The logging function is activated with the "Display" button. The selec‐
ted log is generated as an XML file in the specified layout and shown
in Internet Explorer.
Select "Process Cell" and click on the "Display" button to show all
process cell errors or warnings. Moreover on a selected object you can
right click to select the "Display Log" dialog to also show object-specific
errors or warnings.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
874 Operating Manual, 02/2016, A5E35958174-AA
