9.5.9.4 Formula comparison
With a formula comparison, you can compare two formulas within a formula category.
The formula attributes are displayed on both sides in the comparison header, corresponding
to the selected filter. This is followed by the recipe parameters, transfer parameters and
parameters for output materials and input materials, corresponding to the selected filter. The
attributes are displayed on both sides here as well. The reason for the display on both sides
is that it is not possible to add or delete something in one formula and not in the other formula
within a formula category. Thus, only attributes can be changed.
Comparing formulas
Property Value (left side) Value (right side)
FormP1
<absolute path>
Formula
Name FormP1 FormP1
Version V1.0 V2.0
Recipe Recipe example Recipe example
Last change 08.06.2015 14:36:58 (UTC
+2:00)
01.06.2015 11:06:05
(UTC +2:00)
Input material 1
<Absolute path>
Input material
Setpoint 11 21
Material name Input material 001 Input material 002
Material code E001 E002
Output material 1
<Absolute path>
Output material
Setpoint 15 25
Material name Product 001 Product 002
Material code P001 P002
Parameter1
<Absolute path>
Recipe parameters
Setpoint 20 40
BATCH Control Center
9.5 Recipes
SIMATIC BATCH V8.2
346 Operating Manual, 02/2016, A5E35958174-AA
