Status Symbol Remark
System error There was a system error when downloading.
Check/download OS The PCS 7 OS has not yet been correctly downloaded.
OK
Saves your settings and closes the dialog.
Cancel
Discards your settings and closes the dialog.
Help
Opens the online help for this context.
14.2 BCC menu commands
14.2.1 Program menu
14.2.1.1 New process cell (Program menu)
This function reads in the data of the basic control for a selected process cell. The data of
basic basic consists of the block instances of the SFC types created in the CFC charts or the
SIMATIC BATCH-specific blocks UNIT_BLOCK, IEOP, IEPH, EPAR, and TAG_COLL, as well
as the supplementary data in the hierarchy folders.
14.2.1.2 Updating of the process cell
If you have made changes to the BATCH-relevant process cell data (e.g., in CFC charts with
SFC types/BATCH interface blocks or to type descriptions) in the engineering system (ES),
you must update the process cell data in BatchCC.
Updating process cell data after changes in the engineering system (Page 290)
14.2.1.3 Print (Program menu)
With this function, you can start the printout of the data displayed in the list boxes in BatchCC.
14.2.1.4 Print preview
You can display a print preview of the selected data with this function. The print command is
also provided in the preview window. You cannot edit in the print preview.
Context help references
14.2 BCC menu commands
SIMATIC BATCH V8.2
1048 Operating Manual, 02/2016, A5E35958174-AA
