Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging is activated with the "Display" button. The selected log is
generated as an XML file in the specified layout and displayed in In‐
ternet Explorer.
Select "Station" to show all station errors or warnings. You can also
right-click a selected object and select the "Display log" function to
display object-specific errors or warnings.
Additional functions
No additional functions available.
OK button
Saves your settings and closes the dialog.
Apply button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
14.1.12.7 "Multiproject/Project" selection
Multiproject/project selection
In the "Process cell data" list you have selected the "Multiproject/project" object.
Path in the topmost display field
Logical path from the multiproject
Process cell data
For navigation in the process cell data
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
866 Operating Manual, 02/2016, A5E35958174-AA
