Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging is activated with the "Display" button. The selected log is
generated as an XML file in the specified layout and displayed in In‐
ternet Explorer.
Select "Process cell" and click the "Display" button to show all process
cell errors or warnings. You can also right-click a selected object and
select the "Display log" function to display object-specific errors or
warnings.
Additional functions
Displays: All instance parameters that refer to this data type are listed in a dialog box. Certain
attributes can be selected by means of a special filter.
OK button
Saves your settings and closes the dialog.
Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
14.1.13.4 "Data type parameter" selection, PCC
Data type parameters selection
You have selected the "Data type parameters" object in the "Process cell data" list.
The following functions are exclusively possible with the PCC API:
● Functions such as configuring the distribution topology
● Downloading the project data
● Transferring the batch messages
● Reading/writing the EQM file
● Defining the environment variables
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
968 Operating Manual, 02/2016, A5E35958174-AA
