Display
Below a project (cardinality project/process cell = 1:1) all available batch objects (batch types
and batch instances) are displayed in the process cell tree (left side of the dialog box), and
their attributes are displayed under Properties on the right side of the dialog box.
Specifically the batch objects are:
● Batch types:
– Data types > data type > data type parameters → currently selected element
The system specifies standard data types Output material, Boolean, Input material,
Floating-point number, Integer, and String. By selecting the "Data types" folder, you can
create your own data types. After selection of your own data type, you can edit its data
type parameters.
– Units of measure
– Operation types, phase types, and process tag types
– Equipment properties
● Batch instances:
– Process cell (folder)
– Units (folder)
– Equipment properties
– Equipment modules (EMOD) (folder)
– Neutral folder
– Equipment phases (EPH)
– Parameters of equipment phases
– Equipment operations (EOP)
– Parameters of equipment operations
– Process tags
– Process tag parameters
Runtime name in the dialog header
Display of the runtime name.
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the navigation tree.
Description Any object description by the user.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 969
