14.1.12.14 "Units of measure" selection
Units of measure selection
In the "Process cell data" list you have selected the "Units of measure" object. Units are
created, deleted and edited in the "Shared declarations - Units of measure" folder of the project
in the SIMATIC Manager.
Run time name in the dialog header
Display of the run time name.
Process cell data
For navigation in the process cell data
Properties
Name of the object selected in the process cell tree.
Units of measure
Button
Delete Click on the "Delete" button to open the "Delete units of measure" dialog.
Click on the "Yes" button to delete all units of measure that are not used in
SIMATIC BATCH. Points of use in recipes, libraries and batches cannot be
checked.
This function is useful if you have declared units of measure in SIMATIC
Manager within the global declarations that are not relevant for SIMATIC
BATCH.
Log
"Errors" display field The number of errors for the selected log are displayed.
"Warnings" display field The number of warnings for the selected log are displayed.
"Display" button The logging function is activated with the "Display" button. The selec‐
ted log is generated as an XML file in the specified layout and shown
in Internet Explorer.
Select "Process cell" and click on the "Display" button to show all proc‐
ess cell errors or warnings. Moreover on a selected object you can
right click to select the "Display Log" dialog to also show object-specific
errors or warnings.
Additional functions
Display of possible additional functions.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 877
