Siemens SIMATIC BATCH User Manual

7.3.18.3 Executable functions in a single project
Executable functions for the BATCH types in the BATCH configuration dialog
Function Selected object Description
Generate Batch types
● SFC types: Operation/phase types are generated from SFC
types with EOP/EPH IDs.
● BATCH interface blocks: Batch types (units of measure,
operation/phase types, process tag types) are generated
from the instances of the BATCH interface blocks.
Note: If Batch instances, SFC types or TAGCOLLECT FBs are
modified, the "Generate" function must be run prior to compila‐
tion. The same applies to modifications in the PH, for example
after moving or copying CFC charts.
New
● Phase types
● Operation types
● Process tag types
Creation of phase, operation, and process tag types under the
selected area and creation of the corresponding type parame‐
ters.
Delete
● Data type
● User data type (if present)
● Units of measure
● Phase types
● Operation types
● Process tag types
● Equipment properties
You can delete data types, user data types, units of measure
and equipment properties in the selected folder. All non-in‐
stanced objects are deleted. However, they remain available in
the shared declarations and will appear again during the next
generation. With operation types, phase types and process tag
types, you can select individual objects and delete them as long
as they have not been instanced.
Edit
● Phase types
● Operation types
● Process tag types
Editing the attributes of the batch types and type parameters.
Exception: SFC types
You can find a description of how to edit SFC types in the sec‐
tion "Creating a new SFC type (Page 155)".
Additional functions
Print
Batch types Printing:
Print all batch types of the process cell in tabular form.
Additional function
Display
● User data type (if present)
● Units of measure
● Phase types
● Operation types
● Process tag types
● Equipment properties
List of all instances that refer to this type object. Certain attrib‐
utes can be selected using a filter.
Log Batch types Display of the logs of the executed "Generate" function
To do this you must select the executed function in a drop-down
selection list and then click on the "Display" button.
Engineering
7.3 BATCH engineering
SIMATIC BATCH V8.2
214 Operating Manual, 02/2016, A5E35958174-AA
