"Cancel" button
Exits the dialog without saving your settings.
"Help" button
Opens the online help for this dialog.
14.1.2.4 Color settings
The layout settings made here apply to the BATCH Recipe Editor and the recipe view in
BatchCC during batch control.
The colors of the recipe steps (start, end, substructures,...) and transitions depend on the
status and can be set separately according to text on the icon, icon surface and icon frame.
Note
These settings apply to all applications that are linked to the same database.
Click in a row to change the color of a property. A link symbol appears at the far right in the
highlighted row. Click on the link symbol and select a new color for the selected property.
"OK" button
Exits the dialog and saves your settings.
"Standard" button
Click this button to reset all project settings you have changed in this tab to the default setting
"Yes".
"Apply" button
Saves your settings without closing the dialog.
"Cancel" button
Exits the dialog without saving your settings.
"Help" button
Opens the online help for this dialog.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
734 Operating Manual, 02/2016, A5E35958174-AA
