14.1.12.4 "Connections" selection
In the "Process cell data" list you have selected the "Connections" object.
Runtime name in the dialog header
Logical path within the navigation tree.
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the process cell tree.
The table shows the local S7 connection between the BATCH application on the PC and the
automation system. This is the connection data from NetPro.
Connections
Name of the object selected in the process cell tree.
Update Click this button after you have made changes in the connection configuration
in NetPro. This applies the current connection data from the basic engineering
in the BATCH configuration dialog.
Compile With this, you save and compile the current connection data in the current
project.
Download With this, you download the current connection data to the relevant stations
in the current project.
Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging is activated with the "Display" button. The selected log is
generated as an XML file in the specified layout and displayed in In‐
ternet Explorer.
Select "Connections" to show all connection errors or warnings. You
can also right-click a selected object and select the "Display log" func‐
tion to display object-specific errors or warnings.
Additional functions
"Display" button. Opens your current connection configuration in NetPro.
OK button
Saves your settings and closes the dialog.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
862 Operating Manual, 02/2016, A5E35958174-AA
