S7 program
The following functions are available for your charts in the "S7 program" area:
Button name Function
Compile Opens the "Compile program" dialog from the SIMATIC Man‐
ager.
Download Opens the "Download PLC" dialog from the SIMATIC Manager.
In the case of a complete download, you must first set the CPU
to "STOP" mode manually.
Note: The "download" button is only displayed if S7 programs
are assigned to an automation system.
Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The "Display" button activates the logging. The selected log is gener‐
ated as an XML file with the specified layout and displayed in the In‐
ternet Explorer.
With the "S7 program" selection, all errors or warnings related to the
S7 program are displayed. When you select an object, you can also
right-click and select the "Display log" function to show errors or warn‐
ings for an individual object.
Additional functions
Units: "Display" button: The units assigned to this S7 program are listed in this dialog.
"OK" button
Saves your settings and ends the dialog.
"Apply" button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
"Cancel" button
Closes the dialog without saving changes.
"Help" button
Opens the SIMATIC BATCH online help for this context.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 861
