Toolbar elements Symbol Symbol menu Value
Properties 3
Delete batch 4
Release batch 5
Cancel batch 6
Lock batch 7
Unlock 8
Start batch 9
Pause batch after step 10
Hold batch immediately 11
Resume batch 12
Stop batch 13
Abort batch 14
Abort batch (emergency) 15
Close batch 16
Archive batch 17
Display control recipe 18
Enter comment 19
Update 20
Open with BCC 21
Change 24
25
23
26
Use a negative or a positive value to specify whether or not the function "Undock automatically"
should be used by default. Example: If you enter the value -22 instead of the specified value
22 for the attribute for the "Undock automatically" function, the button is displayed in the OS
control as pressed, that is, the OS Control is automatically shown as undocked.
Default: 1;22;;24;25;23;26;;2;3;4;;5;6;7;8;;9;10;11;12;13;14;15;;16;17;19;;18;20;;21
The attribute can be dynamized with the ToolbarOrderAndVisibility name.
11.5.6.11 ToolbarVisible
Boolean variable.
This attribute specifies whether or not the toolbar is displayed in the control.
Default: Yes, the toolbar is used or displayed.
The attribute can be dynamized with the ToolbarVisible name.
BATCH OS controls
11.5 Control properties references
SIMATIC BATCH V8.2
672 Operating Manual, 02/2016, A5E35958174-AA
