Note:
This is where information on the status of the object is specified.
Used library, formula category, material, roles
The name of the selected object is shown in the left list.
Replace with
This lists the objects in the open Batch process cell.
Back
Goes to the previous page. The previously configured data (assignments) are maintained.
Next
Goes to the next page. If the data on the current page have not been completely processed
an error message will be output and the element with a problem will be marked in the list.
14.2.7.3 Import - Process cell Update
Introduction
In this dialog, the process cell data of the import file is listed in a tree structure in the "Process
cell from import file" column on the left. The assigned elements of the open batch process cell
are listed in the "Current process cell" column. To the left of each element in the tree structure
is a check box with the following meaning:
● White background:: No element from the open batch process cell could be allocated.
● Check mark on a white background: The element and all lower-level elements must be
arranged according to the elements that will be imported.
Note
The assignment is made by matching names.
● Check mark on a gray background: The element could be assigned but at least one lower-
level element has no assignment.
All allocated list elements are specified in the "Current process cell" column. In the "Edited"
column any entry that you change will be marked with an "x". In the "Used element" window
the element from the import file will be displayed that is currently being edited.
Note
Check the assignment made in the left list and correct it if necessary.
Context help references
14.2 BCC menu commands
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 1085
