This attribute defines the sequence of the table columns in the "Parameters" tab of the
properties dialog and in the SIMATIC BATCH OS Properties control. If values are not specified,
the corresponding columns are not displayed in the control.
The following columns are available:
Column name Value
Name 1
Type 2
Data type 3
Low limit 4
Setpoint value 5
High limit 6
Actual value 7
Quality (1) 8
Unit of measure 9
Scaling 10
Material 11
Source 12
Destination 13
Reference 14
Location 15
Location ID 16
Description 17
Time remaining 18
Note: To make the "Time remaining" table column
visible in the control, enter the assigned value 18
manually.
Effective immediately 19
Formula 22
Note: To make the "Formula" table column visible
in the control, enter the assigned value 22 man‐
ually.
(1) The Quality column is not supported and exists only for compatibility reasons.
Default: 1;2;3;4;5;6;7;9;10;11;12;13;14;15;16;17;19
The attribute can be dynamized with the ParametersListColumnOrderAndVisibility name.
11.5.3.10 ParametersListColumnWidth
String.
BATCH OS controls
11.5 Control properties references
SIMATIC BATCH V8.2
654 Operating Manual, 02/2016, A5E35958174-AA
