Additional information
Multiple instancing of the same block types within a unit (Page 205)
14.1.12.21 "Phase type_AF" selection
Phase type selection
You have selected the "Phase type_AF" object in the "Process cell data" list.
Runtime name in the dialog header
Display of the runtime name.
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the process cell tree.
Description The description of the phase type is entered or displayed in this text box.
"Allow operator instruc‐
tion" check box
With this option, you specify whether or not this phase can be used by an
operator instruction.
V4 block Indicates the version of the phase type used.
The following block types are available for selection in the drop-down list
box:
AF24: The block has 24 parameters.
AF12: The block has 12 parameters.
AF6: The block has 6 parameters.
AF16S: The block has 16 parameters.
Using Batch block instances having different versions (EOP, IEOP, SFC-
TYPE ) but the same phase type automatically results in so-called mixed
operation. However mixed operation is permitted exclusively for combina‐
tions of versions 5, 6i, and SFC type. Mixed operation of version V4.02 with
other versions is not allowed.
Allowed versions / combinations are:
Version = 4.02
Version = V5
Version = V6i
Version = V6
Mixed version = V5 / V6i
Mixed version = V5 / V6
Mixed version = V6i / V6
Mixed version = V5 / V6i / V6
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
888 Operating Manual, 02/2016, A5E35958174-AA
