Phase type
Buttons
New Click the "New" button to add a new phase type parameter of the selected
version.
If a phase type parameter is created, the version of the type can no longer
be changed.
Delete Click the "Delete" button to delete the selected phase type.
Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging is activated with the "Display" button. The selected log is
generated as an XML file in the specified layout and displayed in In‐
ternet Explorer.
Select "Process cell" and click the "Display" button to show all process
cell errors or warnings. You can also right-click a selected object and
select the "Display log" function to display object-specific errors or
warnings.
Additional functions
Instances
Display button All instances that refer to this phase type are listed in a dialog.
Or no instance exists.
OK button
Saves your settings and closes the dialog.
Apply button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 889
