9.1.4.9 Output window for messages
Requirement
A PCS 7 OS (WinCC) runs on the BATCH client PC in process mode.
Output window
All the messages for batch control (system messages, process messages, error messages)
that are managed in the WinCC archives can also be displayed in BatchCC.
To display these messages, you can open the output window of the PCS 7 OS (WinCC Alarm
Control) in BatchCC in a separate output window.
You open the output window with the menu command View > Toolbars > Output.
Customizing
● You can customize the properties of the message window (familiar from WinCC), for
example the columns displayed and the selection of messages.
● User settings are entered in the global database and restored the next time you start
BatchCC. Certain settings that are essential for SIMATIC BATCH are exceptions to this,
for example selection of BATCH messages.
● Select a message line and then select "Open control recipe" in the shortcut menu. This
opens the control recipe that matches the message.
BATCH Control Center
9.1 Starting and operating
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 263
