Units of measure
Buttons
Update All BATCH block instances are synchronized with the corresponding batch
types.
This action is always required if a change has been made to batch types
of existing BATCH block instances (e.g., inserting a new parameter, chang‐
ing the unit of measure, etc.).
New A new "Unit of measure" subobject is created below the selected "Units of
measure" object.
Unit of measure
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging is activated with the "Display" button. The selected log is
generated as an XML file in the specified layout and displayed in In‐
ternet Explorer.
Select "Process cell" and click the "Display" button to show all process
cell errors or warnings. You can also right-click a selected object and
select the "Display log" function to display object-specific errors or
warnings.
Additional functions
Display of possible additional functions.
OK button
Saves your settings and closes the dialog.
Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
14.1.13.6 "Unit" selection, PCC
Unit of measure selection
You have selected the "Unit of measure" object in the "Process cell data" list.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 973
