14.1.12.25 "Process tag type" selection for the TAG_COLL block
Process tag type selection
In the list "Process cell data" you have selected the object "process tag type".
Run time name in the dialog header
Display of the run time name.
Process cell data
For navigation in the process cell data
Properties
Name of the object selected in the process cell tree.
Description You can display or enter the description of the process tag type parameter
in this text box.
Process tag type
Buttons
New Click "New" to add a new process tag type.
Delete Click "Delete" to delete the selected process tag type.
Log
"Errors" display field The number of errors for the selected log are displayed.
"Warnings" display field The number of warnings for the selected log are displayed.
"Display" button The "Display" button activates the log. The selected log is generated
as an XML file with the specified layout and displayed in the Internet
Explorer.
The "Display" button is always shows all errors/warnings for the selec‐
ted "Process cell". Moreover on a selected object you can right click
to select the "Display Log" dialog to also show object-specific errors
or warnings.
Additional function
Instances: Display
All the instance parameters that refer to this process tag type are listed in a dialog box.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
896 Operating Manual, 02/2016, A5E35958174-AA
