OK button
Saves your settings and closes the dialog.
Apply button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
14.1.12.42 "EOP parameters" selection
EOP parameters selection
You have selected the "EOP parameters" object in the "Process cell data" list.
Runtime name in the dialog header
Display of the runtime name.
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the process cell tree.
Description Description: The description of the equipment module is displayed in this
text box. You enter description texts in the object properties for the unit in
SIMATIC Manager.
Runtime name Corresponds to the WinCC variable name plus the OS name as prefix.
CFC chart CFC chart name in which the block is placed.
"Open" button
Not possible in the multi‐
project
Click on the "Open" button to open the appropriate CFC chart and select
the block.
High limit This is where the high setpoint limit is displayed that was defined on the
parameter of the appropriate block in the CFC chart. The high limit is dis‐
played for the data types REAL, INTEGER, input and output material. The
Boolean, string and user data types do not have any limits.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 923
