Low limit This displays the low limit of the setpoint defined for the parameter of the
corresponding block in the CFC chart. The low limit is displayed for the data
types REAL, INTEGER, input and output material. The Boolean, string and
user data types do not have any limits.
Setpoint This displays the setpoint defined for the parameter of the corresponding
block in the CFC chart. The following applies: "low limit <= setpoint <= high
limit". The validity is checked during validation.
"Parameters" button Activating this button takes you to the corresponding phase type parameter.
With the "Back" button of the phase type parameter, you return to beginning
selection.
EOP parameters
Button
Compile
Only for single project not
for multiproject
All batch instance blocks of the CFC chart of the selected object are read
in. This also implicitly involves a check for consistency with the batch types
and conformity to ISA-88.
Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging is activated with the "Display" button. The selected log is
generated as an XML file in the specified layout and displayed in In‐
ternet Explorer.
Select "Process cell" and click the "Display" button to show all process
cell errors or warnings. You can also right-click a selected object and
select the "Display log" function to display object-specific errors or
warnings.
Additional functions
Display of possible additional functions.
OK button
Saves your settings and closes the dialog.
Apply button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Cancel button
Closes the dialog without saving changes.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
924 Operating Manual, 02/2016, A5E35958174-AA
