● Releasing recipes for production (Page 317)
● Status of the recipes and status changes (Page 318)
9.1.5.3 Master recipes
Storing recipe procedures
In this area, you can store the recipe procedures created with the BATCH Recipe Editor
according to the technological structure of your process cell. With the reference (can be set in
a dialog box) to a formula category and ultimately to a concrete formula, you have a complete
master recipe. There are both flat and hierarchical master recipes. If you have large numbers
of master recipes, these can be stored in different folders (without semantics) to achieve a
better structure.
Position of the objects
0DVWHU
UHFLSHV
UHFLSH
SURF
GXUHV
UHIHUHQFH
WRIRUPXOD
FDWHJRU\
0DVWHU
UHFLSH
IROGHU
BATCH Control Center
9.1 Starting and operating
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 273
